Material Housing Material Aluminum Alloy
Front Panel Tempered Glass (2.5D edge processing)
Mortise Lock Type
European Standard
Backset
55 mm
Axe Distance
72 mm
Square Spindle
7.8 mm
Faceplate (H×W)
24×235 mm; squared standard
Built-in Detectors
Auxiliary Latch (Anti-card system), Deadbolt
Unlocking Methods
Fingerprint, Card, Passcode (6 or 8 digits), ZSmart App, Voice Assistant, Mechanical Key
Capacity
User: 100, Fingerprint: 100,
Passcode: 100, Card: 50,
Mobile App Records: last 6 months
Card Reader
IC Card @13.56 MHz
NFC Supported
Audio Prompt Language
English, Spanish
Wireless Communication
Wi-Fi (IEEE 802.11b/g/n) @ 2.4 GHz
BLE 5.0 (only for network configuration)
Emergency Power
USB Type-C Interface, DC 5V
Battery Life
approximately 10 months
* Battery life is estimated based on an average of 10 accesses per day while maintaining the Wi-Fi connection
Voice Assistant Platform
Amazon Alexa, Google Assistant
Supported App
ZSmart
Door Compatibility
Door Type
Wooden Swing Door
Door Thickness
35 to 60 mm (standard)
Opening Direction
All Direction (reversible lever design)
General
Net Weight
2.5 kg
Gross Weight
3.0 kg
Product Dimensions (H×W×T)
Exterior: 330.9×75.2×25.3 mm
Interior: 330.9×75.2×24.5 mm
* Lever not included
Package Dimensions (L×W×H)
225.0×130.0×430.0 mm
Operating Temperature
-20°C to 55°C (-4°F to 131°F)
Operating Humidity
10% to 90% RH (Non-condensing)
Certifications
CE
Standard Functions
Users Management via Mobile App, Remote Unlock, Voice Control, Temporary Passcode
(dynamic, periodic), Anti-Peeping Codes (up to 20 digits), Doorbell, Volume Setting, Language Setting, Passage Mode, Do-Not-Disturb Mode, Admin Lockout Mode, Unclosed Door Alarm, Tamper Alarm, Low Battery Alarm, Consecutive Attempts Alarm, Firmware OTA
